2011 Jayco Pinnacle 36 REQS

$39,999

PAYMENTS AS LOW AS $262 BIWEEKLY OAC

Here’s a quality fifth wheel with all the extras to make camping life very enjoyable. With 4 slides , front king bedroom , side bath w/ skylight over the shower , and large kitchen/ living area ,you’ll have ample space for guests . other features : rear entertainment center w/ pop up tv & Jensen stereo system , ceiling fan , two AC units , slideout awnings, power awning , generator prepped , rear ladder , exterior shower , aluminum wheels , rear pull out storage tray.

UVW 6220 kg

SKU: RB0146 Categories: ,
Standard Construction Features
  • 2″ x 3″longitudinal floor joists placed on 16″ centers
  • 5/8″ tongue-and-groove plywood floor decking
  • Bead-foam insulation in sidewalls and roof
  • Cabinetry crafted with screwed-stile construction
  • Enclosed and protected electric-powered slideout motors
  • Euro styled aerodynamic front and rear gel-coated caps
  • Frame prepped for bike rack/cargo tray
  • Heated and enclosed fresh water and holding tanks
  • I-Class cambered structural steel I-beam frame
  • Long pin box
  • Polar Barrier insulation package
  • Poly Flex one piece moisture barrier underbelly covering
  • R-21 insulation in roof, R-8 in sidewalls, R-24 in floor and underbelly, R-15 in slideout floors
  • Reflective foil insulation in main floor
  • Reflective foil insulation in slideout floors
  • Seamless one-piece rubber roof
  • TuffShell vacuum-bonded 5″ crowned laminated roof (R-21)
  • TuffShell vacuum-bonded laminated sidewalls (R-8)
  • Welded tubular aluminum sidewall framework



Wheels & Tires:
Wheels Composition Aluminum
Number Of Axles 2
Tire 16 Inch
Spare Tire Location Exterior Mounted

Technical Specifications:
Length (ft/m) 39.92 / 12.2
Width (in/mm) 96 / 2438.4
Height (in/mm) 155 / 3937
Interior Height (in/mm) 107.5 / 2730.5
Length (ft/ft) 39
Length (ft/in) 11
Dry Weight (lbs/kg) 12620 / 5724.4
Payload Capacity (lbs/kgs) 3330 / 1510.5
GVWR (lbs/kgs) 15950 / 7234.9
Hitch Weight (lbs/kgs) 2615 / 1186.2

Capacities Standard
Number Of Fresh Water Holding Tanks 1
Total Fresh Water Tank Capacity (gal/l) 87 / 329.3
Number Of Gray Water Holding Tanks 1
Total Gray Water Tank Capacity (gal/l) 87 / 329.3
Number Of Black Water Holding Tanks 1
Total Black Water Tank Capacity (gal/l) 52 / 196.8
Propane Tank (s) Standard
Number Of Propane Tanks 2
Total Propane Tank Capacity (gal/lbs) 14.2 / 60

Exterior:
Body Material Aluminum
Sidewall Construction Fiberglass
Number of Doors 1
Number of Slideouts 4
Power Retractable Slideout Yes
Number of Awnings 1
Awning Length (ft/m) 16 / 4.9
Power Retractable Awning Yes
